- Product Model A3909GLYTR-T
- Brand Allegro MicroSystems
- RoHS Yes
- Description IC HALF BRIDGE DRIVER 1A 10MSOP
- Classification Full Half-Bridge (H Bridge) Drivers
Technical Details
- Package / Case 10-TFSOP, 10-MSOP (0.118", 3.00mm Width) Exposed Pad
- Mounting Type Surface Mount
- Interface Logic
- Operating Temperature -40°C ~ 150°C (TJ)
- Output Configuration Half Bridge (4)
- Voltage - Supply 4V ~ 18V
- Rds On (Typ) 1.6Ohm LS + HS
- Applications DC Motors, General Purpose, Stepper Motors
- Current - Output / Channel 1A
- Technology DMOS
- Voltage - Load 4V ~ 18V
- Supplier Device Package 10-MSOP-EP
- Fault Protection Current Limiting, Over Temperature
- Load Type Inductive
