- Product Model NCV7703CD2R2G
- Brand Sanyo Semiconductor/onsemi
- RoHS Yes
- Description IC HALF BRIDGE DRVR 1.1A 14SOIC
- Classification Full Half-Bridge (H Bridge) Drivers
-
PDF
Technical Details
- Package / Case 14-SOIC (0.154", 3.90mm Width)
- Mounting Type Surface Mount
- Interface SPI
- Operating Temperature -40°C ~ 150°C (TJ)
- Output Configuration Half Bridge (3)
- Voltage - Supply 3.15V ~ 5.25V
- Rds On (Typ) 800mOhm LS, 800mOhm HS
- Applications DC Motors, General Purpose
- Current - Output / Channel 1.1A
- Technology Power MOSFET
- Voltage - Load 5.5V ~ 40V
- Supplier Device Package 14-SOIC
- Fault Protection Current Limiting, ESD, Over Temperature, Over Voltage, UVLO
- Load Type Inductive
