- Product Model NCP45540IMNTWG-H
- Brand Sanyo Semiconductor/onsemi
- RoHS Yes
- Description IC PWR SWITCH N-CHAN 1:1 12DFN
- Classification Power Distribution Switches, Load Drivers
-
PDF
Technical Details
- Features Power Good, Slew Rate Controlled
- Package / Case 12-VFDFN Exposed Pad
- Output Type N-Channel
- Mounting Type Surface Mount
- Number of Outputs 1
- Interface On/Off
- Switch Type General Purpose
- Operating Temperature -40°C ~ 85°C (TA)
- Output Configuration High Side
- Rds On (Typ) 4.8mOhm
- Input Type Non-Inverting
- Voltage - Load 0.5V ~ 13.5V
- Voltage - Supply (Vcc/Vdd) 3V ~ 5.5V
- Current - Output (Max) 14A
- Ratio - Input:Output 1:1
- Supplier Device Package 12-DFN (3x3)
- Fault Protection Over Temperature, UVLO
