- Product Model FAN73912MX
- Brand Sanyo Semiconductor/onsemi
- RoHS Yes
- Description IC GATE DRVR HALF-BRIDGE 16SOIC
- Classification Gate Drivers
-
PDF
Technical Details
- Package / Case 16-SOIC (0.295", 7.50mm Width)
- Mounting Type Surface Mount
- Operating Temperature -40°C ~ 125°C (TJ)
- Voltage - Supply 12V ~ 20V
- Input Type Non-Inverting
- High Side Voltage - Max (Bootstrap) 1200 V
- Supplier Device Package 16-SOIC
- Rise / Fall Time (Typ) 25ns, 15ns
- Channel Type Synchronous
- Driven Configuration High-Side and Low-Side
- Number of Drivers 2
- Gate Type IGBT, N-Channel MOSFET
- Logic Voltage - VIL, VIH 6V, 9.5V
- Current - Peak Output (Source, Sink) 2A, 3A
- DigiKey Programmable Not Verified
