- Product Model 2ED1324S12PXUMA1
- Brand IR (Infineon Technologies)
- RoHS No
- Description HALF-BRIDGE GATE DRIVER
- Classification Gate Drivers
-
PDF
Inventory:2463
Technical Details
- Package / Case 20-BSSOP (0.295", 7.50mm Width)
- Mounting Type Surface Mount
- Operating Temperature -40°C ~ 150°C (TJ)
- Voltage - Supply 13V ~ 25V
- Input Type Non-Inverting
- High Side Voltage - Max (Bootstrap) 1200 V
- Supplier Device Package PG-DSO-20-U03
- Rise / Fall Time (Typ) 48ns, 48ns
- Channel Type Synchronous
- Driven Configuration Half-Bridge
- Number of Drivers 1
- Gate Type IGBT
- Logic Voltage - VIL, VIH 0.7V, 0.7V
- Current - Peak Output (Source, Sink) 2.3A, 2.3A
