Technical Details

• Package / Case 16-SOIC (0.154", 3.90mm Width), 15 Leads
• Mounting Type Surface Mount
• Operating Temperature -40°C ~ 125°C (TJ)
• Duty Cycle 50%
• Frequency - Switching 60kHz ~ 500kHz
• Internal Switch(s) No
• Output Isolation Isolated
• Topology Half-Bridge
• Voltage - Supply (Vcc/Vdd) 9.5V ~ 20V
• Supplier Device Package 16-SOIC
• Fault Protection Current Limiting, Over Temperature, Over Voltage, Short Circuit
• Voltage - Start Up 10.5 V
• Control Features Frequency Control
• Grade Automotive
• Qualification AEC-Q100
