Technical Details

• Features Load Discharge, Slew Rate Controlled
• Package / Case 4-UDFN
• Output Type N-Channel
• Mounting Type Surface Mount
• Number of Outputs 1
• Interface On/Off
• Switch Type General Purpose
• Operating Temperature -40°C ~ 150°C (TJ)
• Output Configuration High Side
• Rds On (Typ) 26mOhm
• Input Type Non-Inverting
• Voltage - Load 1.8V ~ 5.5V
• Voltage - Supply (Vcc/Vdd) Not Required
• Current - Output (Max) 4A
• Ratio - Input:Output 1:1
• Supplier Device Package 4-DFN (1.2x1.6)
• Fault Protection Current Limiting (Adjustable), Over Temperature, Over Voltage, Short Circuit, UVLO
