- Product Model VN7004SLHTR
- Brand STMicroelectronics
- RoHS Yes
- Description HIGH-SIDE DRIVER WITH CURRENTSEN
- Classification Power Distribution Switches, Load Drivers
-
PDF
Technical Details
- Features Load Discharge, Status Flag
- Package / Case OctaPAK (7 Leads + Tab)
- Output Type N-Channel
- Mounting Type Surface Mount
- Number of Outputs 1
- Interface Logic
- Switch Type General Purpose
- Operating Temperature -40°C ~ 150°C (TJ)
- Output Configuration High Side
- Rds On (Typ) 4mOhm
- Input Type Non-Inverting
- Voltage - Supply (Vcc/Vdd) 4V ~ 28V
- Current - Output (Max) 135A
- Ratio - Input:Output 1:1
- Supplier Device Package OctaPAK 7+1
- Fault Protection Current Limiting (Adjustable), Open Load Detect, Over Temperature, Over Voltage, Reverse Current, UVLO
