- Product Model TPS272C45CRHFR
- Brand Texas Instruments
- RoHS Yes
- Description 36-V, 45-M, 3-A, 2-CH, INDUSTRIA
- Classification Power Distribution Switches, Load Drivers
-
PDF
Technical Details
- Features Load Discharge, Slew Rate Controlled
- Package / Case 24-VFQFN Exposed Pad
- Output Type N-Channel
- Mounting Type Surface Mount
- Number of Outputs 2
- Interface On/Off
- Switch Type General Purpose
- Operating Temperature -40°C ~ 125°C (TJ)
- Output Configuration High Side
- Rds On (Typ) 45mOhm
- Input Type Non-Inverting
- Voltage - Load 4.5V ~ 36V
- Voltage - Supply (Vcc/Vdd) 3V ~ 5.5V
- Current - Output (Max) 5.8A
- Ratio - Input:Output 1:1
- Supplier Device Package 24-VQFN (5x4)
- Fault Protection Current Limiting (Adjustable), Over Temperature, Over Voltage, UVLO
