- Product Model BTN70301EPAXUMA1
- Brand IR (Infineon Technologies)
- RoHS Yes
- Description IC HALF BRIDGE DRVR 7A TSDSO-14
- Classification Full Half-Bridge (H Bridge) Drivers
-
PDF
Technical Details
- Features Diagnostic Enable, Enable, SENSE
- Package / Case 14-TSSOP (0.154", 3.90mm Width) Exposed Pad
- Mounting Type Surface Mount
- Interface Logic
- Operating Temperature -40°C ~ 150°C (TJ)
- Output Configuration Half Bridge
- Voltage - Supply 6V ~ 18V
- Rds On (Typ) 20mOhm LS, 12mOhm HS
- Applications DC Motors, General Purpose
- Current - Output / Channel 7A
- Current - Peak Output 17A
- Technology SMART7
- Supplier Device Package PG-TSDSO-14
- Fault Protection Current Limiting, Over Current, Over Temperature, Over Voltage, Short Circuit
- Load Type Inductive
