- Product Model DRV8904QPWPRQ1
- Brand Texas Instruments
- RoHS Yes
- Description IC HALF BRIDGE DRVR 6A 24HTSSOP
- Classification Full Half-Bridge (H Bridge) Drivers
-
PDF
Technical Details
- Features Charge Pump, Slew Rate Controlled
- Package / Case 24-PowerTSSOP (0.173", 4.40mm Width)
- Mounting Type Surface Mount
- Interface Logic, PWM, SPI
- Operating Temperature -40°C ~ 125°C (TA)
- Output Configuration Half Bridge (4)
- Voltage - Supply 3V ~ 5.5V
- Rds On (Typ) 750mOhm LS, 750mOhm HS
- Applications DC Motors, General Purpose
- Current - Output / Channel 6A
- Technology MOSFET (Metal Oxide)
- Voltage - Load 4.5V ~ 32V
- Supplier Device Package 24-HTSSOP
- Fault Protection Over Current, Over Voltage, UVLO
- Load Type Inductive, Capacitive, Resistive
- Grade Automotive
- Qualification AEC-Q100
