Technical Details

• Package / Case 16-DIP (0.300", 7.62mm)
• Output Type Complementary
• Mounting Type Through Hole
• Number of Elements 1
• Function Master Reset
• Type D-Type
• Operating Temperature -55°C ~ 125°C (TA)
• Voltage - Supply 3V ~ 18V
• Current - Quiescent (Iq) 4 µA
• Current - Output High, Low 6.8mA, 6.8mA
• Trigger Type Positive Edge
• Clock Frequency 14 MHz
• Input Capacitance 5 pF
• Supplier Device Package 16-PDIP
• Max Propagation Delay @ V, Max CL 120ns @ 15V, 50pF
• Number of Bits per Element 4
