1
$94.0613
$94.0613
10
$90.9303
$909.3030
25
$88.0720
$2,201.8000
| TYPE | DESCRIPTION |
| Mfr | Triad Magnetics |
| Series | Chassis Mount: World Series™ |
| Package | Box |
| Product Status | ACTIVE |
| Size / Dimension | 140.00mm Dia x 60.00mm W |
| Mounting Type | Chassis Mount |
| Type | Toroidal |
| Weight | 9.3 lbs (4.2 kg) |
| Termination Style | Wire Leads |
| Primary Winding(s) | Dual |
| Secondary Winding(s) | Dual |
| Power - Max | 500VA |
| Voltage - Isolation | 4000Vrms |
| Current - Output (Max) | Parallel 20.8A, Series 10.4A |
| Voltage - Primary | 115V, 230V |
| Height - Seated (Max) | 66.0mm |
| Voltage - Secondary (Full Load) | Parallel 24V, Series 48V |
| Center Tap | No |
