Technical Details

• Package / Case 16-DIP (0.300", 7.62mm)
• Mounting Type Through Hole
• Operating Temperature -40°C ~ 85°C (TA)
• On-State Resistance (Max) 30Ohm (Typ)
• Supplier Device Package 16-PDIP
• Voltage - Supply, Single (V+) 3V ~ 5.5V
• Voltage - Supply, Dual (V±) ±4.5V ~ 5.5V
• Charge Injection 11pC
• Crosstalk -85dB @ 1MHz
• Switch Circuit SPST - NO/NC
• Multiplexer/Demultiplexer Circuit 1:1
• Switch Time (Ton, Toff) (Max) 200ns, 120ns (Typ)
• Channel Capacitance (CS(off), CD(off)) 9pF, 9pF
• Current - Leakage (IS(off)) (Max) 100pA
• Number of Circuits 4
