- Product Model ADG709CRUZ
- Brand Linear Technology (Analog Devices, Inc.)
- RoHS Yes
- Description IC SWITCH SP4TX2 4.5OHM 16TSSOP
- Classification Analog Switches, Multiplexers, Demultiplexers
-
PDF
Technical Details
- Package / Case 16-TSSOP (0.173", 4.40mm Width)
- Mounting Type Surface Mount
- Operating Temperature -40°C ~ 125°C (TA)
- On-State Resistance (Max) 4.5Ohm
- -3db Bandwidth 55MHz
- Supplier Device Package 16-TSSOP
- Voltage - Supply, Single (V+) 1.8V ~ 5.5V
- Voltage - Supply, Dual (V±) ±2.5V
- Charge Injection 3pC
- Crosstalk -80dB @ 1MHz
- Switch Circuit SP4T
- Multiplexer/Demultiplexer Circuit 4:1
- Channel-to-Channel Matching (ΔRon) 400mOhm
- Switch Time (Ton, Toff) (Max) 14ns, 8ns (Typ)
- Channel Capacitance (CS(off), CD(off)) 13pF, 42pF
- Current - Leakage (IS(off)) (Max) 10pA (Typ)
- Number of Circuits 2
