- Product Model AD7686BRMZ
- Brand Linear Technology (Analog Devices, Inc.)
- RoHS Yes
- Description IC ADC 16BIT SAR 10MSOP
- Classification Analog to Digital Converters (ADC)
-
PDF
Technical Details
- Package / Case 10-TFSOP, 10-MSOP (0.118", 3.00mm Width)
- Mounting Type Surface Mount
- Number of Bits 16
- Configuration S/H-ADC
- Data Interface SPI, DSP
- Reference Type External
- Operating Temperature -40°C ~ 85°C
- Voltage - Supply, Analog 5V
- Voltage - Supply, Digital 5V
- Sampling Rate (Per Second) 500k
- Input Type Pseudo-Differential
- Number of Inputs 1
- Supplier Device Package 10-MSOP
- Architecture SAR
- Ratio - S/H:ADC 1:1
- Number of A/D Converters 1
