- Product Model ADG633YRUZ-REEL7
- Brand Linear Technology (Analog Devices, Inc.)
- RoHS Yes
- Description IC SWITCH SPDT X 3 75OHM 16TSSOP
- Classification Analog Switches, Multiplexers, Demultiplexers
-
PDF
Technical Details
- Package / Case 16-TSSOP (0.173", 4.40mm Width)
- Mounting Type Surface Mount
- Operating Temperature -40°C ~ 125°C (TA)
- On-State Resistance (Max) 75Ohm
- -3db Bandwidth 580MHz
- Supplier Device Package 16-TSSOP
- Voltage - Supply, Single (V+) 2V ~ 12V
- Voltage - Supply, Dual (V±) ±2V ~ 6V
- Charge Injection 2pC
- Crosstalk -90dB @ 1MHz
- Switch Circuit SPDT
- Multiplexer/Demultiplexer Circuit 2:1
- Channel-to-Channel Matching (ΔRon) 800mOhm
- Switch Time (Ton, Toff) (Max) 95ns, 40ns
- Channel Capacitance (CS(off), CD(off)) 4pF, 7pF
- Current - Leakage (IS(off)) (Max) 200pA
- Number of Circuits 3
