- Product Model ADG713BRUZ-REEL7
- Brand Linear Technology (Analog Devices, Inc.)
- RoHS Yes
- Description IC SW SPST-NO/NCX4 4OHM 16TSSOP
- Classification Analog Switches, Multiplexers, Demultiplexers
-
PDF
Technical Details
- Package / Case 16-TSSOP (0.173", 4.40mm Width)
- Mounting Type Surface Mount
- Operating Temperature -40°C ~ 85°C (TA)
- On-State Resistance (Max) 4Ohm
- -3db Bandwidth 200MHz
- Supplier Device Package 16-TSSOP
- Voltage - Supply, Single (V+) 1.8V ~ 5.5V
- Charge Injection 3pC
- Crosstalk -90dB @ 10MHz
- Switch Circuit SPST - NO/NC
- Multiplexer/Demultiplexer Circuit 1:1
- Switch Time (Ton, Toff) (Max) 11ns, 6ns (Typ)
- Channel Capacitance (CS(off), CD(off)) 10pF, 10pF
- Current - Leakage (IS(off)) (Max) 100pA
- Number of Circuits 4
