Technical Details

• Package / Case 16-TSSOP (0.173", 4.40mm Width)
• Mounting Type Surface Mount
• Operating Temperature -40°C ~ 125°C (TA)
• On-State Resistance (Max) 480mOhm
• -3db Bandwidth 29MHz
• Supplier Device Package 16-TSSOP
• Voltage - Supply, Single (V+) 1.8V ~ 5.5V
• Charge Injection 70pC
• Crosstalk -99dB @ 100kHz
• Switch Circuit DPDT
• Multiplexer/Demultiplexer Circuit 4:2
• Channel-to-Channel Matching (ΔRon) 40mOhm
• Switch Time (Ton, Toff) (Max) 30ns, 17ns
• Channel Capacitance (CS(off), CD(off)) 58pF
• Current - Leakage (IS(off)) (Max) 200pA (Typ)
• Number of Circuits 2
