Technical Details

• Package / Case 20-DIP (0.300", 7.62mm)
• Mounting Type Through Hole
• Number of Bits 12
• Configuration MUX-S/H-ADC
• Data Interface SPI
• Reference Type External
• Operating Temperature -40°C ~ 85°C
• Voltage - Supply, Analog 5V, ±5V
• Voltage - Supply, Digital 5V, ±5V
• Sampling Rate (Per Second) 50k
• Input Type Differential, Single Ended
• Number of Inputs 4, 8
• Supplier Device Package 20-PDIP
• Architecture SAR
• Ratio - S/H:ADC 1:1
• Number of A/D Converters 1
