- Product Model DRV8304HRHAR
- Brand Texas Instruments
- RoHS Yes
- Description IC GATE DRVR HI/LOW SIDE 40VQFN
- Classification Gate Drivers
Inventory:4000
Technical Details
- Package / Case 40-VFQFN Exposed Pad
- Mounting Type Surface Mount
- Operating Temperature -40°C ~ 125°C
- Voltage - Supply 6V ~ 38V
- Input Type Non-Inverting
- Supplier Device Package 40-VQFN (6x6)
- Rise / Fall Time (Typ) 300ns, 150ns
- Channel Type 3-Phase
- Driven Configuration High-Side or Low-Side
- Number of Drivers 3
- Gate Type N-Channel MOSFET
- Logic Voltage - VIL, VIH 0.8V, 1.5V
- Current - Peak Output (Source, Sink) 150mA, 300mA
- DigiKey Programmable Not Verified
