Technical Details

• Package / Case 28-SSOP (0.209", 5.30mm Width)
• Mounting Type Surface Mount
• Operating Temperature 0°C ~ 70°C (TA)
• On-State Resistance (Max) 100Ohm
• Supplier Device Package 28-SSOP
• Voltage - Supply, Single (V+) 2.7V ~ 16V
• Voltage - Supply, Dual (V±) ±2.7V ~ 8V
• Charge Injection 2pC
• Crosstalk -92dB @ 100kHz
• Multiplexer/Demultiplexer Circuit 16:1
• Channel-to-Channel Matching (ΔRon) 1.8Ohm
• Switch Time (Ton, Toff) (Max) 150ns, 150ns
• Channel Capacitance (CS(off), CD(off)) 11pF, 80pF
• Current - Leakage (IS(off)) (Max) 100pA
• Number of Circuits 1
