Technical Details

• Package / Case SOT-23-6 Thin, TSOT-23-6
• Mounting Type Surface Mount
• Operating Temperature -55°C ~ 125°C (TA)
• On-State Resistance (Max) 25Ohm
• -3db Bandwidth 200MHz
• Supplier Device Package 6-TSOP
• Voltage - Supply, Single (V+) 2V ~ 5.5V
• Charge Injection 3pC
• Switch Circuit SPDT
• Multiplexer/Demultiplexer Circuit 2:1
• Channel-to-Channel Matching (ΔRon) 2Ohm
• Switch Time (Ton, Toff) (Max) 14ns, 8ns
• Channel Capacitance (CS(off), CD(off)) 10pF, 10pF
• Current - Leakage (IS(off)) (Max) 1nA
• Number of Circuits 1
