Technical Details

• Features Schmitt Trigger
• Package / Case 5-TSSOP, SC-70-5, SOT-353
• Mounting Type Surface Mount
• Logic Type NAND Gate
• Operating Temperature -55°C ~ 125°C
• Voltage - Supply 2V ~ 5.5V
• Current - Output High, Low 8mA, 8mA
• Number of Inputs 2
• Supplier Device Package SC-88A (SC-70-5/SOT-353)
• Input Logic Level - High 2.25V ~ 3.7V
• Input Logic Level - Low 0.65V ~ 1.45V
• Max Propagation Delay @ V, Max CL 9.7ns @ 5V, 50pF
• Number of Circuits 1
• Current - Quiescent (Max) 1 µA
