Technical Details

• Package / Case 16-TSSOP (0.173", 4.40mm Width)
• Mounting Type Surface Mount
• Operating Temperature -40°C ~ 105°C (TA)
• On-State Resistance (Max) 75Ohm
• -3db Bandwidth 35MHz
• Supplier Device Package 16-TSSOP
• Voltage - Supply, Single (V+) 2V ~ 5.5V
• Multiplexer/Demultiplexer Circuit 8:1
• Channel-to-Channel Matching (ΔRon) 1.3Ohm
• Switch Time (Ton, Toff) (Max) 14ns, 14ns
• Channel Capacitance (CS(off), CD(off)) 0.5pF, 23.4pF
• Current - Leakage (IS(off)) (Max) 100nA
• Grade Automotive
• Number of Circuits 1
• Qualification AEC-Q100
