- Product Model DAC8814ICDBT
- Brand Texas Instruments
- RoHS Yes
- Description IC DAC 16BIT A-OUT 28SSOP
- Classification Digital to Analog Converters (DAC)
-
PDF
Technical Details
- Package / Case 28-SSOP (0.209", 5.30mm Width)
- Output Type Current - Unbuffered
- Mounting Type Surface Mount
- Number of Bits 16
- Data Interface SPI
- Reference Type External
- Operating Temperature -40°C ~ 85°C
- Voltage - Supply, Analog 2.7V ~ 5.5V
- Voltage - Supply, Digital 2.7V ~ 5.5V
- Settling Time 500ns (Typ)
- Supplier Device Package 28-SSOP
- Architecture Multiplying DAC
- Number of D/A Converters 4
- INL/DNL (LSB) ±1 (Max), ±1 (Max)
- Differential Output No
- DigiKey Programmable Not Verified
