- Product Model MAX77816AEWP+T
- Brand Maxim Integrated / Analog Devices
- RoHS Yes
- Description IC REG BUCK-BOOST ADJ 5A 20WLP
- Classification Voltage Regulators - DC DC Switching Regulators
-
PDF
Technical Details
- Package / Case 20-WFBGA, WLBGA
- Output Type Adjustable
- Mounting Type Surface Mount
- Number of Outputs 1
- Function Step-Up, Step-Down
- Current - Output 5A
- Operating Temperature -40°C ~ 85°C (TA)
- Output Configuration Positive
- Frequency - Switching 2.5MHz
- Voltage - Input (Max) 5.5V
- Topology Buck-Boost
- Supplier Device Package 20-WLP (1.83x2.13)
- Synchronous Rectifier No
- Voltage - Output (Max) 5.14V
- Voltage - Input (Min) 2.3V
- Voltage - Output (Min/Fixed) 2.6V
