Technical Details

• Features Slew Rate Controlled
• Package / Case 24-TSSOP (0.154", 3.90mm Width) Exposed Pad
• Output Type N-Channel
• Mounting Type Surface Mount
• Number of Outputs 8
• Interface SPI
• Switch Type Relay, Solenoid Driver
• Operating Temperature -40°C ~ 150°C (TJ)
• Output Configuration High Side or Low Side
• Rds On (Typ) 1Ohm
• Voltage - Load 3V ~ 28V
• Voltage - Supply (Vcc/Vdd) 3V ~ 5.5V
• Current - Output (Max) 330mA
• Ratio - Input:Output 1:8
• Supplier Device Package PG-TSDSO-24-21
• Fault Protection Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage
• Grade Automotive
• Qualification AEC-Q100
