- Product Model MAX5719AGSD+
- Brand Linear Technology (Analog Devices, Inc.)
- RoHS Yes
- Description IC DAC 20BIT 14SOIC
- Classification Digital to Analog Converters (DAC)
-
PDF
Technical Details
- Package / Case 14-SOIC (0.154", 3.90mm Width)
- Output Type Voltage - Unbuffered
- Mounting Type Surface Mount
- Number of Bits 20
- Data Interface SPI, DSP
- Reference Type External
- Operating Temperature -40°C ~ 105°C
- Voltage - Supply, Analog 4.5V ~ 5.5V
- Voltage - Supply, Digital 4.5V ~ 5.5V
- Settling Time 1.5µs (Typ)
- Supplier Device Package 14-SOIC
- Architecture R-2R
- Number of D/A Converters 1
- INL/DNL (LSB) ±1, ±1
- Differential Output No
- DigiKey Programmable Not Verified
