- Product Model AD8582ARZ
- Brand Linear Technology (Analog Devices, Inc.)
- RoHS Yes
- Description IC DAC 12BIT V-OUT 24SOIC
- Classification Digital to Analog Converters (DAC)
-
PDF
Technical Details
- Package / Case 24-SOIC (0.295", 7.50mm Width)
- Output Type Voltage - Buffered
- Mounting Type Surface Mount
- Number of Bits 12
- Data Interface Parallel
- Reference Type Internal
- Operating Temperature -40°C ~ 85°C
- Voltage - Supply, Analog 5V
- Voltage - Supply, Digital 5V
- Settling Time 16µs (Typ)
- Supplier Device Package 24-SOIC
- Architecture R-2R
- Number of D/A Converters 2
- INL/DNL (LSB) ±0.75, ±0.75
- Differential Output No
- DigiKey Programmable Not Verified
