- Product Model TS5205CX5 RFG
- Brand TSC (Taiwan Semiconductor)
- RoHS Yes
- Description IC REG LIN POS ADJ 150MA SOT25
- Classification Voltage Regulators - Linear, Low Drop Out (LDO) Regulators
-
PDF
Technical Details
- Package / Case SC-74A, SOT-753
- Output Type Adjustable
- Mounting Type Surface Mount
- Current - Output 150mA
- Operating Temperature -40°C ~ 125°C (TJ)
- Output Configuration Positive
- Current - Quiescent (Iq) 125 µA
- Voltage - Input (Max) 16V
- Number of Regulators 1
- Supplier Device Package SOT-25
- Voltage - Output (Max) 8V
- Voltage - Output (Min/Fixed) 1.24V
- Control Features Current Limit, Enable
- PSRR 75dB (100Hz)
- Voltage Dropout (Max) 0.275V @ 150mA
- Protection Features Over Temperature
- Current - Supply (Max) 1.9 mA
