Technical Details

• Package / Case 6-VDFN Exposed Pad
• Output Type Fixed
• Mounting Type Surface Mount
• Current - Output 1A
• Operating Temperature -40°C ~ 125°C (TJ)
• Output Configuration Positive
• Current - Quiescent (Iq) 50 µA
• Voltage - Input (Max) 5.5V
• Number of Regulators 1
• Supplier Device Package 6-DFN (3x3)
• Voltage - Output (Min/Fixed) 3.3V
• Control Features Enable, Power Good
• PSRR 65dB ~ 62dB (1kHz ~ 10kHz)
• Voltage Dropout (Max) 0.4V @ 1A
• Protection Features Over Current, Over Temperature, Short Circuit
• Current - Supply (Max) 300 µA
