Technical Details

• Package / Case 16-UFQFN
• Mounting Type Surface Mount
• Operating Temperature -40°C ~ 125°C (TA)
• On-State Resistance (Max) 115Ohm
• -3db Bandwidth 1GHz
• Supplier Device Package 16-miniQFN (1.8x2.6)
• Voltage - Supply, Single (V+) 3V ~ 12V
• Voltage - Supply, Dual (V±) ±3V ~ 5V
• Charge Injection 1.4pC
• Crosstalk -74dB @ 10MHz
• Switch Circuit SPST - NO
• Multiplexer/Demultiplexer Circuit 1:1
• Channel-to-Channel Matching (ΔRon) 600mOhm
• Switch Time (Ton, Toff) (Max) 50ns, 35ns
• Channel Capacitance (CS(off), CD(off)) 3pF, 3pF
• Current - Leakage (IS(off)) (Max) 100pA
• Number of Circuits 4
