- Product Model AD7801BRZ
- Brand Linear Technology (Analog Devices, Inc.)
- RoHS Yes
- Description IC DAC 8BIT V-OUT 20SOIC
- Classification Digital to Analog Converters (DAC)
-
PDF
Technical Details
- Package / Case 20-SOIC (0.295", 7.50mm Width)
- Output Type Voltage - Buffered
- Mounting Type Surface Mount
- Number of Bits 8
- Data Interface Parallel
- Reference Type External
- Operating Temperature -40°C ~ 105°C
- Voltage - Supply, Analog 2.7V ~ 5.5V
- Voltage - Supply, Digital 2.7V ~ 5.5V
- Settling Time 2µs
- Supplier Device Package 20-SOIC
- Architecture Current Source
- Number of D/A Converters 1
- INL/DNL (LSB) ±1 (Max), ±1 (Max)
- Differential Output No
- DigiKey Programmable Not Verified
