Technical Details

• Package / Case 10-VFDFN Exposed Pad, CSP
• Output Type Adjustable
• Mounting Type Surface Mount
• Current - Output 2A
• Operating Temperature -40°C ~ 125°C
• Output Configuration Positive
• Current - Quiescent (Iq) 8 mA
• Voltage - Input (Max) 5.5V
• Number of Regulators 1
• Supplier Device Package 10-LFCSP-WD (3x3)
• Voltage - Output (Max) 2.3V
• Voltage - Output (Min/Fixed) 1.2V
• Control Features Enable
• PSRR 61dB ~ 45dB (1kHz ~ 1MHz)
• Voltage Dropout (Max) 0.28V @ 2A
• Protection Features Over Current, Over Temperature, Under Voltage Lockout (UVLO)
• Current - Supply (Max) 14 mA
