Technical Details

• Package / Case 8-PowerSOIC (0.154", 3.90mm Width)
• Output Type Adjustable
• Mounting Type Surface Mount
• Current - Output 300mA
• Operating Temperature -40°C ~ 150°C
• Output Configuration Positive
• Current - Quiescent (Iq) 18 µA
• Voltage - Input (Max) 40V
• Number of Regulators 1
• Supplier Device Package 8-SO PowerPad
• Voltage - Output (Max) 40V
• Voltage - Output (Min/Fixed) 1.5V
• Grade Automotive
• PSRR 70dB (100Hz)
• Voltage Dropout (Max) 0.52V @ 200mA
• Protection Features Over Current, Over Temperature, Reverse Polarity, Under Voltage Lockout (UVLO)
• Current - Supply (Max) 400 µA
• Qualification AEC-Q100
