- Product Model LT3066IDE#PBF
- Brand Linear Technology (Analog Devices, Inc.)
- RoHS Yes
- Description IC REG LIN POS ADJ 500MA 12DFN
- Classification Voltage Regulators - Linear, Low Drop Out (LDO) Regulators
-
PDF
Technical Details
- Package / Case 12-WFDFN Exposed Pad
- Output Type Adjustable
- Mounting Type Surface Mount
- Current - Output 500mA
- Operating Temperature -40°C ~ 125°C
- Output Configuration Positive
- Current - Quiescent (Iq) 125 µA
- Voltage - Input (Max) 45V
- Number of Regulators 1
- Supplier Device Package 12-DFN (4x3)
- Voltage - Output (Max) 19V
- Voltage - Output (Min/Fixed) 0.6V
- Control Features Current Limit, Enable, Power Good, Soft Start
- PSRR 85dB (120Hz)
- Voltage Dropout (Max) 0.51V @ 500mA
- Protection Features Over Current, Over Temperature, Reverse Polarity
- Current - Supply (Max) 25 mA
