- Product Model AD5689RTCPZ-EP-RL7
- Brand Linear Technology (Analog Devices, Inc.)
- RoHS Yes
- Description IC DAC 16BIT V-OUT 16LFCSP
- Classification Digital to Analog Converters (DAC)
-
PDF
Technical Details
- Package / Case 16-WFQFN Exposed Pad, CSP
- Output Type Voltage - Buffered
- Mounting Type Surface Mount
- Number of Bits 16
- Data Interface SPI
- Reference Type External, Internal
- Operating Temperature -55°C ~ 125°C
- Voltage - Supply, Analog 2.7V ~ 5.5V
- Voltage - Supply, Digital 1.8V ~ 5.5V
- Settling Time 8µs
- Supplier Device Package 16-LFCSP (3x3)
- Architecture String DAC
- Number of D/A Converters 2
- INL/DNL (LSB) ±1, ±1 (Max)
- Differential Output No
- DigiKey Programmable Not Verified
