Technical Details

• Features Schmitt Trigger
• Package / Case 14-TSSOP (0.173", 4.40mm Width)
• Mounting Type Surface Mount
• Logic Type NAND Gate
• Operating Temperature -55°C ~ 125°C
• Voltage - Supply 3V ~ 18V
• Current - Output High, Low 3.4mA, 3.4mA
• Number of Inputs 2
• Supplier Device Package 14-TSSOP
• Input Logic Level - High 3.6V ~ 10.8V
• Input Logic Level - Low 0.9V ~ 4V
• Max Propagation Delay @ V, Max CL 130ns @ 15V, 50pF
• Number of Circuits 4
• Current - Quiescent (Max) 4 µA
