- Product Model NCP81071BZR2G
- Brand Sanyo Semiconductor/onsemi
- RoHS Yes
- Description IC GATE DRVR LOW-SIDE 8MSOP
- Classification Gate Drivers
-
PDF
Technical Details
- Package / Case 8-TSSOP, 8-MSOP (0.118", 3.00mm Width) Exposed Pad
- Mounting Type Surface Mount
- Operating Temperature -40°C ~ 140°C (TJ)
- Voltage - Supply 4.5V ~ 20V
- Input Type Non-Inverting
- Supplier Device Package 8-MSOP-EP
- Rise / Fall Time (Typ) 8ns, 8ns
- Channel Type Independent
- Driven Configuration Low-Side
- Number of Drivers 2
- Gate Type N-Channel MOSFET
- Logic Voltage - VIL, VIH 1.2V, 1.8V
- Current - Peak Output (Source, Sink) 5A, 5A
- DigiKey Programmable Not Verified
