- Product Model AP1013CEN
- Brand Asahi Kasei Microdevices Corporation (AKM)
- RoHS Yes
- Description IC HALF BRIDGE DRIVER 1.3A 16QFN
- Classification Full Half-Bridge (H Bridge) Drivers
-
PDF
Technical Details
- Package / Case 16-UFQFN Exposed Pad
- Mounting Type Surface Mount
- Interface Logic
- Operating Temperature -30°C ~ 150°C (TJ)
- Output Configuration Half Bridge (2)
- Voltage - Supply 2.7V ~ 5.5V
- Applications General Purpose
- Current - Output / Channel 1.3A
- Current - Peak Output 5A
- Technology Power MOSFET
- Voltage - Load 2V ~ 18V
- Supplier Device Package 16-QFN (3x3)
- Fault Protection Over Temperature, UVLO
- Load Type Inductive
