- Product Model MCP14A0151T-E/CH
- Brand Roving Networks (Microchip Technology)
- RoHS Yes
- Description IC GATE DRVR HI/LOW SIDE SOT23-6
- Classification Gate Drivers
-
PDF
Technical Details
- Package / Case SOT-23-6
- Mounting Type Surface Mount
- Operating Temperature -40°C ~ 150°C (TJ)
- Voltage - Supply 4.5V ~ 18V
- Input Type Inverting
- Supplier Device Package SOT-23-6
- Rise / Fall Time (Typ) 11.5ns, 10ns
- Channel Type Single
- Driven Configuration Half-Bridge
- Number of Drivers 1
- Gate Type N-Channel, P-Channel MOSFET
- Logic Voltage - VIL, VIH 0.8V, 2V
- Current - Peak Output (Source, Sink) 1.5A, 1.5A
- DigiKey Programmable Not Verified
