Technical Details

• Package / Case 6-WDFN Exposed Pad
• Output Type Fixed
• Mounting Type Surface Mount
• Current - Output 150mA
• Operating Temperature -40°C ~ 125°C
• Output Configuration Positive
• Current - Quiescent (Iq) 80 µA
• Voltage - Input (Max) 6.5V
• Number of Regulators 1
• Supplier Device Package 6-WSON (2x2)
• Voltage - Output (Min/Fixed) 3.3V
• Control Features Enable
• Grade Automotive
• PSRR 70dB ~ 45dB (100Hz ~ 1MHz)
• Voltage Dropout (Max) 0.3V @ 150mA
• Protection Features Over Current, Over Temperature, Reverse Polarity, Under Voltage Lockout (UVLO)
• Current - Supply (Max) 100 µA
• Qualification AEC-Q100
