- Product Model ADG5412BFBRUZ
- Brand Linear Technology (Analog Devices, Inc.)
- RoHS Yes
- Description IC SW SPST-NOX4 11.5OHM 16TSSOP
- Classification Analog Switches, Multiplexers, Demultiplexers
-
PDF
Technical Details
- Package / Case 16-TSSOP (0.173", 4.40mm Width)
- Mounting Type Surface Mount
- Operating Temperature -40°C ~ 125°C (TA)
- On-State Resistance (Max) 11.5Ohm
- -3db Bandwidth 270MHz
- Supplier Device Package 16-TSSOP
- Voltage - Supply, Single (V+) 8V ~ 44V
- Voltage - Supply, Dual (V±) ±5V ~ 22V
- Charge Injection -640pC
- Crosstalk -90dB @ 1MHz
- Switch Circuit SPST - NO
- Multiplexer/Demultiplexer Circuit 1:1
- Channel-to-Channel Matching (ΔRon) 50mOhm
- Switch Time (Ton, Toff) (Max) 500ns, 515ns
- Channel Capacitance (CS(off), CD(off)) 12pF, 11pF
- Current - Leakage (IS(off)) (Max) 500pA
- Number of Circuits 4
