Technical Details

• Package / Case 16-TSSOP (0.173", 4.40mm Width)
• Mounting Type Surface Mount
• Operating Temperature -40°C ~ 125°C (TA)
• On-State Resistance (Max) 11.5Ohm
• -3db Bandwidth 270MHz
• Supplier Device Package 16-TSSOP
• Voltage - Supply, Single (V+) 8V ~ 44V
• Voltage - Supply, Dual (V±) ±5V ~ 22V
• Charge Injection -640pC
• Crosstalk -70dB @ 1MHz
• Switch Circuit SPST - NO/NC
• Multiplexer/Demultiplexer Circuit 1:1
• Channel-to-Channel Matching (ΔRon) 50mOhm
• Switch Time (Ton, Toff) (Max) 500ns, 515ns
• Channel Capacitance (CS(off), CD(off)) 12pF, 11pF
• Current - Leakage (IS(off)) (Max) 250pA
• Number of Circuits 4
