- Product Model FAN7391MX
- Brand Sanyo Semiconductor/onsemi
- RoHS Yes
- Description IC GATE DRVR HALF-BRIDGE 14SOP
- Classification Gate Drivers
-
PDF
Technical Details
- Package / Case 14-SOIC (0.154", 3.90mm Width)
- Mounting Type Surface Mount
- Operating Temperature -40°C ~ 150°C (TJ)
- Voltage - Supply 10V ~ 20V
- Input Type Non-Inverting
- High Side Voltage - Max (Bootstrap) 600 V
- Supplier Device Package 14-SOIC
- Rise / Fall Time (Typ) 25ns, 20ns
- Channel Type Independent
- Driven Configuration Half-Bridge
- Number of Drivers 2
- Gate Type IGBT, N-Channel MOSFET
- Logic Voltage - VIL, VIH 1.2V, 2.5V
- Current - Peak Output (Source, Sink) 4.5A, 4.5A
- DigiKey Programmable Not Verified
