- Product Model ADP1196ACBZ-02-R7
- Brand Linear Technology (Analog Devices, Inc.)
- RoHS Yes
- Description IC PWR SWITCH N-CHAN 1:1 6WLCSP
- Classification Power Distribution Switches, Load Drivers
Inventory:16546
Technical Details
- Features Slew Rate Controlled
- Package / Case 6-WFBGA, WLCSP
- Output Type N-Channel
- Mounting Type Surface Mount
- Number of Outputs 1
- Interface On/Off
- Switch Type General Purpose
- Operating Temperature -40°C ~ 105°C (TJ)
- Output Configuration High Side or Low Side
- Rds On (Typ) 10mOhm
- Input Type Non-Inverting
- Voltage - Load 1.83V ~ 5.5V
- Voltage - Supply (Vcc/Vdd) Not Required
- Current - Output (Max) 3A
- Ratio - Input:Output 1:1
- Supplier Device Package 6-WLCSP (1.45x0.95)
- Fault Protection Current Limiting (Fixed), Over Temperature
