Technical Details

• Package / Case 8-VFSOP (0.091", 2.30mm Width)
• Mounting Type Surface Mount
• Operating Temperature -40°C ~ 85°C (TA)
• On-State Resistance (Max) 13Ohm
• -3db Bandwidth 300MHz
• Supplier Device Package 8-VSSOP
• Voltage - Supply, Single (V+) 1.65V ~ 5.5V
• Crosstalk -58dB @ 1MHz
• Switch Circuit SPDT
• Multiplexer/Demultiplexer Circuit 2:1
• Channel-to-Channel Matching (ΔRon) 2Ohm (Max)
• Switch Time (Ton, Toff) (Max) 4.5ns, 8ns
• Channel Capacitance (CS(off), CD(off)) 10pF
• Current - Leakage (IS(off)) (Max) 100nA
• Number of Circuits 1
