Technical Details

• Features Schmitt Trigger
• Package / Case 14-SOIC (0.154", 3.90mm Width)
• Mounting Type Surface Mount
• Logic Type NAND Gate
• Operating Temperature -55°C ~ 125°C
• Voltage - Supply 4.5V ~ 5.5V
• Current - Output High, Low 4mA, 4mA
• Number of Inputs 2
• Supplier Device Package 14-SOIC
• Input Logic Level - High 1.9V ~ 2.1V
• Input Logic Level - Low 0.5V ~ 0.6V
• Max Propagation Delay @ V, Max CL 33ns @ 4.5V, 50pF
• Number of Circuits 4
• Current - Quiescent (Max) 2 µA
