Technical Details

• Features Load Discharge, Status Flag
• Package / Case 6-UDFN Exposed Pad
• Output Type P-Channel
• Mounting Type Surface Mount
• Number of Outputs 1
• Interface On/Off
• Switch Type USB Switch
• Operating Temperature -40°C ~ 125°C (TJ)
• Output Configuration High Side
• Rds On (Typ) 70mOhm
• Input Type Non-Inverting
• Voltage - Load 2.7V ~ 5.5V
• Voltage - Supply (Vcc/Vdd) Not Required
• Current - Output (Max) 2.5A
• Ratio - Input:Output 1:1
• Supplier Device Package U-DFN2020-6
• Fault Protection Current Limiting (Fixed), Over Temperature, Reverse Current, UVLO
